Our GalvinAssist® healthcare showers provide safe and reliable showering for both able-bodied people and people with disabilities. Our designs take into consideration the needs of care facilities to assist in ensuring the showering experience is easy and efficient.
Options
- Choice of white or chrome plated PVC hose and handpiece
Features
- Grade 304 stainless steel grab rail with satin finsih
- Hygienic health safe flange covers
- ABS slide cradle fastened and tensioned to the grab rail for handset support and movement
- Tough white ABS / chrome plated handpiece
- Flexible smooth PVC reinforced white / chrome plated hoses
- Chrome on brass wall outlet elbow
- Interchangeable spigot and separate licensed dual check/non-return valves to prevent back-siphonage
- AS 1428.1 accessible compliant
Technical Information
- WELS: 3 Star Rating (8L/min) / (8.5L/min)
- Nominal Flow Rate (LPM): 7.92 / 8.24
- WaterMark: AS/NZS 3662 Lic. WMK26191
- Inlet: 1/2" BSP
- Outlet: Handheld Shower
- Working Pressure Range (KPa): 50 Min - 500 Max
- Working Temperature Range (°C): 5 Min - 80 Max
- Construction: Brass
- Finish: Chrome
* The hygienic health safe flange cover with Thermoplastic Elastomer (TPE) fitted seal prevents grime such as soap scum, body fluids, ointments and aqueous-based fluids accumulating behind the flange cover and creating possible serious health issues.
